Morgana UFO 1 Folder

MORGANA UFO 1 FOLDER NO UFO 5 CROSS FOLD UNIT

The popular Morgana UFO1 Folding Machine is easy to set up and will fold formats up to SRA 2. Suction feed with on the run loading for high productivity. Each fold plate measurement is easily visible and quick to change saving time on job changes. Complete with batch counter.

Technical Description

Suction fed 2 plate folder

Variable speed rollers and stream delivery

Caliper roller settings

Quick and easy changeover of jobs

Batch counter

POWER REQUIREMENT – 1ph

MAXIMUM SPEED A4 S.P.H. 30,000

MAXIMUM SHEET SIZE Length 640mm Width 457mm

MINIMUM SHEET SIZE Length 150mm Width 120mm

MAXIMUM PAPER WEIGHT 240gsm

MINIMUM PAPER WEIGHT 45gsm

Overall Dimensions not including cross fold unit

Length 1910mm

Width 785mm

Height 1460mm

Weight 185kgs
