Morgana Documaster Pro, Crease, Fold, Stitch, Trim, Square spine

No longer available

Morgana Documaster Pro, Crease, Fold, Stitch, Trim, Square spine

£10,000 (GBP)

United Kingdom

Description

Morgana Documaster Pro - Crease and Fold - Stitch and Trim - Squareback The DocuMaster Pro is a highly versatile and multi-tasking machine that incorporates SmartScreen touch screen technology. It has been specifically designed to address the challenges associated with finishing pre-collated sets. With the DocuMaster Pro, you can create high-quality booklets without the need to remove covers and center spreads for pre-creasing, only to manually reinsert them back into sets. The SmartScreen control unit allows you to easily program creasing for covers, center spreads, or all sheets in the book if required. This latest version of the DocuMaster Pro eliminates tedious and time-consuming operations by creasing the sheets as part of the feeding and bookletmaking process.


One of the key features of the DocuMaster Pro is its 7" SmartScreen touch screen, which provides an intuitive and user-friendly interface. It can handle multi-weight pre-collated stocks and is JDF and variable data ready. The machine is highly versatile and can accommodate stock up to 0.4mm (approximately 400 gsm). With a speed of 1560 books per hour, it offers efficient production capabilities. The DocuMaster Pro also features unlimited alphanumeric memory, a sonic double detector, perforating as standard, and the ability to crease without cracking.


Controlled by the innovative 7" SmartScreen panel, the DocuMaster Pro allows you to input instructions regarding book size, number of pages, crease position, and more. All settings and adjustments can be easily made using the user-friendly SmartScreen interface, which utilizes symbols for simplicity. The machine also offers an alphanumeric memory that allows you to store and name an unlimited number of jobs, making job recall easier.


The DocuMaster Pro is JDF ready and can seamlessly integrate into a complete workflow and MIS package. It can handle variable data books and is equipped with an optional variable data camera system, which is simple to use. The camera is set to read a fixed point on the booklet's cover or any other page, providing added convenience. Key Product Features • Takes multi weight pre-collated stocks • Intuitive and easy to use • JDF & variable data ready • High versatile • Takes stock up to 0.4mm (approx 400 gsm)* • Rule and matrix guaranteed for life • 1200 books per hour • Unlimited alpha numeric memory • Sonic double detector • Perforating as standard • Crease without cracking Crease & Fold Maximum speed A4 S.P.H. (crease only) 6800 Maximum sheet size L 630mm x W 330mm Minimum sheet size 210mm x 140mm Maximum paper thickness 0.4mm (approx 400 gsm)* including laminated material Minimum paper thickness 0.11mm (approx 80gsm)* Maximum number of creases per sheet 16 Maximum number programmed applications Unlimited alpha numeric Maximum number of folds per sheet 1 Minimum incremental adjustment 0.1mm Dimensions L 2700mm x W 720mm x H 1185mm Weight 399kgs Power requirement 240v 50/60hz Bookletmaker Productivity Up to 1200 bph Maximum sheet size L 460mm x W 320mm Minimum sheet size 210mm x 140mm Maximum cover thickness 0.38mm (approx 350gsm)* Minimum inside sheet paper thickness 0.11mm (approx 80gsm)* Maximum book thickness 23 sheets 0.11 (approx 80gsm)* Maximum number programmed applications Unlimited alpha numeric Maximum number of folds per sheet 1 Maximum staple pitch 138mm Minimum staple pitch 115mm Maximum trim 25mm Dimensions L 2700mm x W 720mm x H 1185mm (including Squareback) Weight 399kgs Power requirement 240v 50/60hz


Finance Available


Kennet Equipment Leasing is one of the UK’s leading providers of business equipment finance and asset leasing, enabling customers to invest in the very latest business equipment without drawing on critical working capital.


https://www.kennet-leasing.co.uk/finance-calculator-mvgc/

Specifications

ManufacturerMorgana
ModelDocumaster
ConditionUsed
Stock Number2549
