Twin Tower Horizon vac 100 + SPF20a booklet maker and FC20 Trimmer

Twin Tower Horizon vac 100 + SPF20a booklet maker and FC20 Trimmer

£15,000 (GBP)

United Kingdom

orWhatsApp:+44 (0) 7884 423 812

Description

Twin tower horizon vac100 20 sheets The VAC 100 collator features a patented rotary-pulse vacuum feed system, providing flawless feeding on virtually any stock, at speeds up to 8,000 sets per hour. The VAC-100 is equipped with a touch-screen display panel that is very easy to use. The graphical user interface allows anyone in your production area to operate the VAC- 100 collator, without any special skills or training. All operating errors or jams are graphically illustrated on the screen for easy identification and quick resolution. Maximum sheet size: 350mm x 500mm Minimum sheet size: 148 x 148mm Sheet weight range: 60gsm to 250gsm Bin pile height: 55mm Production speed: Up to 8,000 sets per hour Power Requirement/Consumption 220 , 60 HZ, 1 Phase / 1,700 W, 9 amps. World wide transformers can be supplied Weight/Dimensions: 639.5 lbs. / 26” L x 32” W x 77” SPF20A Stitch Fold system Horizon SPF-20a/FC-20a heavy duty automated set-up stitchfold trim with Hohner stitching heads. Books Speed P/H: 4000 Sheet Book Size: A4/A5/A6/CD insert finished size Sheet Size 4.7" x 7.1" to 13.8" x 19.7" Finish Size 3.5" x 4.7" to 9.8" x 13.8" Stitching Wire - Standard No.25 (0.5 mm) (0.02") Machine Weight 1,035 lb. Horizon FC-20 Trimmer Book Size (Before Trim) 3.5" x 4.7" to 9.8" x 13.8" Finish Size 3.3" x 4.7" to 9.8" x 13.8" Trimming Length .79" max. Trimming Thickness .16" max Production Speed up to 3,600 booklets/hr. Machine Weight 507 lb. At Promotional Printing Machinery we offer a quick turnaround once we have received payment for your item, usually 2 - 3 working days UK, (other countries may vary) depending on the size of your purchase, unless otherwise agreed. If you require installation we can supply one of our experienced engineering team to do this for you at extra cost.Our UK sales are shipped out using our local haulage company, the items are fully secured to wooden pallets and sealed with film to weatherpro...

Specifications

ManufacturerHorizon
ConditionUsed
Stock Number2468
