Horizon PF-40L folding machine

No longer available

Horizon PF-40L folding machine

£3,750 Excluding VAT

Lancaster, United Kingdom


Horizon PF-40L


Paper Folder

Sheet Feeding System Air rotor system

Sheet Size (Width x Length) Max. 320 x 630 mm/ 12.59” x 24.80”

- The fold pattern is limited depending on the sheet length and the stopper adjustable range. For a sheet 430 mmor longer, only sheets of up to 105 gsm can be folded.

Min. 125 x 128 mm/ 4.93” x 5.04”

A3 / B4 / A4 / B5 / 11” x 17” / 8.5” x 14” / 8.5” x 11” / 5.5” x 8.5”

Sheet Weight Range Normal Paper: 52 to 157 gsm

Coated Paper: 73 to 157 gsm

Feeder Stack Height Max. 105 mm/ 4.13”

Fold Patterns Single Fold, Double Parallel Fold, Short Fold, Accordion-Fold, Letter Fold, Open Gate Fold

Production Speed 270 sheets per minutes (A3 single fold)

390 sheets per minutes (A4 single fold)The PF-40L combines high-volume suction feed capabilities with the intelligent automation that Horizon products are so well known for. The 1,000 sheet capacity top-fed system is the same suction feed system as is used on both the highly popular VAC Collators and PF-P330 Folder providing for reliable mark-free feeding from static laden digitally printed sheets as well as conventional prints

At Promotional Printing Machinery Limited we provide a quick turnaround, which is usually 2-3 days once payment is received depending on the size of your order.

If you require installation we can provide one of our experienced engineers to do this for you at extra cost.

Our UK sales are shipped out using our local haulage company, the items are fully secured to wooden pallets and covered with shrink wrap film to protect them during transport.

Export machines are sealed into strong wood crates that are sourced from sustainable materials, which are collected by our shipping agent and distributed to you by either Air, Road or Sea.

We only accept payment via bank transfer or cash on collection. A VAT invoice will be supplied with the machine. PayPal payment is not accepted.


ModelHorizon PF-40L
Stock Number2410
